ESP32-WROVER-E WCH JTAG DevKit
29,99 €
incl. 19% VAT plus Shipping Costs
A development board that bundles the ESP32 and JTAG interface chip together. Plug and play JTAG debugging with the help of an WCH CH347T chip.
1 in stock
Shipping within Germany is free of charge!
- Satisfaction Guaranteed
- No Hassle Refunds
- Secure Payments
Description
This EasyDevKit combines the ESP32 WROVER-E with a JTAG debugging chip that is capable also for the UART connection. No need to buy an extra JTAG debug board! No need to connect two board for JTAG debugging!
It’s easily debuggable with Espressif IDF and OpenOCD. Just upload your program normally via UART which is also included in this board. Then start OpenOCD and debug your program line-by-line via the JTAG debugger.
Unique features:
- ESP32-WROVER-E with PCB antenna and 16 MB flash and 8 MB PSRAM
- WCH CH347T chip which connects the USB port to the ESP32 UART and JTAG pins
- LED for JTAG activity
- 2x 19 pin headers soldered
- Pin compatible with the official Espressif ESP32-DevKitC V4
- Micro USB connector
- USB cable not included
Reviews
There are no reviews yet.
